Flipped Double Holding Pressure Type Valve Test Bench
Suitable for gate valves, globe valves, ball valves, control valves, check valves and other straight- flange connection valve seal and valve body strength performance test and the activated pressure setting of relief valve, et
Clamping pressure valve type is hold, hold press claws clamping flange, no external influence on the test
Valve Test medium could be water, gas,or oil, by customer choice
Test bed side table can be moved to adjust the length of the valve position when the pressure test is going on .
One end of the table can be flipped 90 °to the valve test ,suitable for the safety valve testing.
Product Introduction
Our Flipped Double Holding Pressure Valve Test Bench is designed for high-efficiency performance testing of flanged valves. This advanced hydraulic testing equipment combines a flipping mechanism with a double-sided pressure holding system. It allows operators to perform both shell strength tests and seat sealing tests with unmatched safety and precision. It is the ideal solution for valve manufacturers, repair workshops, and power plants. Request Your Quote Today!
1) Suitable for gate valves, globe valves, ball valves, control valves, check valves and other straight-flange connection valve seal and valve body strength performance test and the activated pressure setting of relief valve, et
2) Clamping pressure valve type is hold, hold press claws clamping flange, no external influence on the test
3) Valve Test medium could be water, gas,or oil, by customer choice
4) Test bed side table can be moved to adjust the length of the valve position when the pressure test is going on .
5) One end of the table can be flipped 90 °to the valve test ,suitable for the safety valve testing.
Technical parameter
Customized models and pressure ranges are available upon request.Download Full Technical Datasheet
Model | SYTF150/10-32 | SYTF350/5-32 | SYTF600/6-20 |
Valve ND (nn) | 20-150 | 50-350 | 300-600 |
Test pressure (Mpa) | 32-1.6 | 32-1.6 | 20-1.6 |
Voltage (V) | 380 | 380 | 380 |
Applications
This pressure test bench is widely used in:
Valve Manufacturing Factories (Quality Control)
Petrochemical & Refinery Plants (Maintenance)
Power Generation Stations
Water Treatment Facilities
Natural Gas Pipeline Projects
Whether for production acceptance testing, routine inspection, or certification preparation, this bench delivers reliable results.Contact Our Engineering Team for Recommendation.
Compliance & Standard Certifications
Our valve test equipment is built to meet or exceed international testing standards, including:我
API (American Petroleum Institute) Pressure Testing Criteria
ISO Valve Inspection StandardsISO
CE Certified Electrical & Safety ComplianceCE
Documentation and certificates can be provided to satisfy procurement and compliance requirements.
Looking for a pressure test bench tailored to your project requirements?
Provide your valve type, pressure range, and test conditions — we’ll respond with a tailored solution within 24 hours.
Flipped Double Holding Pressure Type Valve Test Bench picture
